Multilayer Chip Varistor for Voltage Surge Suppres

PhotoCategoryApplicationTech SpecificationDimensions Code JIS/EIASeriesDownload
SDV-A1608
Multilayer Varistorfor Signal line5.5V to 30V 丨 120pF to 820pF1608 [0603 inch]SDV-A

SDV+Series+of+Multilayer+Chip+Varistor

SDV-A2012
Multilayer Varistorfor Signal line5.5V to 30V 丨 180pF to 2000pF2012 [0805 inch]SDV-A

Same as above

SDV-E1005
Multilayer Varistorfor Signal line5.5V to 26V 丨 15pF to 100pF1005 [0402 inch]SDV-E

Same as above

SDV-E1608
Multilayer Varistorfor Signal line5.5V to 26V 丨 18pF to 100pF1608 [0603 inch]SDV-E

Same as above

SDV-E2012
Multilayer Varistorfor Signal line5.5V to 30V 丨 18pF to 100pF2012 [0805 inch]SDV-E

Same as above

SDV-H1005
Multilayer Varistorfor Signal line14V to 26V 丨 0.5pF to 12pF1005 [0402 inch]SDV-H

Same as above

SDV-H1608
Multilayer Varistorfor Signal line14V to 48V 丨 0.5pF to 12pF1608 [0603 inch]SDV-H

Same as above

SDV-S0603
Multilayer Varistorfor Signal line5.5V to 9V丨 0.5pF to 2pF0603 [0201 inch]SDV-S

Same as above

SDV-S1005
Multilayer Varistorfor Signal line5.5V to 18V 丨 0.5pF to 12pF1005 [0402 inch]SDV-S

Same as above

SDV-S1608
Multilayer Varistorfor Signal line5.5V to 18V 丨 0.5pF to 12pF1608 [0603 inch]SDV-S

Same as above

SDVL1608-HS
Multilayer Varistorfor Surge Current Suppression9V to 100V 丨 20A to 150A1608 [0603 inch]SDVL1608-HS

SDVL-HSSeriesofMultilayerChipVaristorforSurgeCurrentSuppression

SDVL2016-HS
Multilayer Varistorfor Surge Current Suppression9V to 150V 丨 100A to 700A2016 [0806 inch]SDVL2016-HS

Same as above

SDVL3216-HS
Multilayer Varistorfor Surge Current Suppression9V to 100V 丨 150A to 500A3216 [1206 inch]SDVL3216-HS

Same as above

SDVL3225-HS
Multilayer Varistorfor Surge Current Suppression9V to 100V 丨 200A to 1500A3225 [1210 inch]SDVL3225-HS

Same as above

SDVL4532-HS
Multilayer Varistorfor Surge Current Suppression9V to 150V 丨 500A to 3000A4532 [1812 inch]SDVL4532-HS

Same as above

SDVL5650-HS
Multilayer Varistorfor Surge Current Suppression9V to 150V 丨 800A to 5000A5650 [2220 inch]SDVL5650-HS

Same as above

SVMH2016
Multilayer Varistorfor Super High Voltage Suppression150V to 275V 丨 70A to 180A2016 [0806 inch]SVMH2016

SVMH+Series+of+Multilayer+Chip+Varistor+of+Super+High+Voltage

SVMH3216
Multilayer Varistorfor Super High Voltage Suppression150V to 300V丨 100A to 300A3216 [1206 inch]SVMH3216

Same as above

SVMH3225
Multilayer Varistorfor Super High Voltage Suppression150V to 300V 丨 200A to 600A3225 [1210 inch]SVMH3225

Same as above

SVMH4532
Multilayer Varistorfor Super High Voltage Suppression150V to 300V 丨 400A to 800A4532 [1812 inch]SVMH4532

Same as above

SVMH5650
Multilayer Varistorfor Super High Voltage Suppression150V to 300V 丨 800A to 1500A5650 [2220 inch]SVMH5650

Same as above
