Inductors for High Frequency

PhotoCategoryApplicationTech SpecificationDimensions Code JIS/EIASeriesDownload
SDCL0402H-01
Multilayer/High QInductor for High Frequency0.2 to 33nH 丨 90 to 320mA0402[01005 inch]SDCL0402H-01

SDCL0402H_T01+Series+of+Multilayer+Chip+Ceramic+Inductor

SDCL0603Q-02B03
Multilayer/High Q Inductors for High Frequency0.6 to 120nH 丨 80 to 850mA0603 [0201 inch]SDCL0603Q-02B03

SDCL0603Q_02-B03+Series+of+Multilayer+Chip+Ceramic+Inductor

SDCL1005C
Multilayer/STDInductor for High Frequency0.6 to 360nH 丨 50 to 800mA1005 [0402 inch]SDCL1005C

SDCL-D+Series+of+Multilayer+Chip+Ceramic+Inductor

SDCL1608C
Multilayer/STDInductor for High Frequency1.0 to 470nH 丨 150 to 500mA1608 [0603 inch]SDCL1608C

Same as above

HQ0402H
Multilayer/High QInductor for High Frequency0.2 to 33nH 丨 120 to 990mA0402 [01005 inch]HQ0402H

HQ-H+Series+of+Multilayer+Chip+High+Q+Inductor

HQ0603H
Multilayer/High QInductor for High Frequency0.6 to 47nH 丨 130 to 1000mA0603 [0201 inch]HQ0603H

Same as above

HQ0402Q
Multilayer/High QInductor for High Frequency0.2 to 56nH 丨 100 to 1000mA0402 [01005 inch]HQ0402Q

HQ-Q+Series+of+Multilayer+Chip+High+Q+Inductor

HQ0603Q
Multilayer/High QInductor for High Frequency0.6 to 150nH 丨 80 to 1100mA0603 [0201 inch]HQ0603Q

Same as above

UHQ0402H
Multilayer/Supper QInductor for High Frequency0.2 to 20nH 丨 140 to 990mA0402 [01005 inch]UHQ0402H

UHQ-H+Series+of+Multilayer+Chip+Super+High+Q+Inductor

HQ1005
Multilayer/High QInductor for High Frequency1.0 to 15nH 丨 430 to 1000mA1005 [0402 inch]HQ1005

HQ1005C+Series+of+Multilayer+Chip+High+Q+Inductor

SDHL1005
Multilayer/High SRFInductor for High Frequency1.0 to 100nH 丨 100 to 500mA1005 [0402 inch]SDHL1005

SDHL+Series+of+Multilayer+Chip+High+Frequency+Inductor

SDHL1608
Multilayer/High SRFInductor for High Frequency10 to 180nH 丨 150 to 500mA1608 [0603 inch]SDHL1608

Same as above

MWSD0603C
Wire Wound/STD Inductor for High Frequency1.0 to 15nH 丨 230 to 900mA0.53×0.4×0.4MWSD0603C

MWSD-C+series+of+Wire+Wound+Chip+Ceramic+Inductor

MWSD0804C
Wire Wound/STDInductor for High Frequency0.8 to 56nH 丨 130 to 1800mA0.8×0.4×0.4MWSD0804C

Same as above

MWSD1005C
Wire Wound/STDInductor for High Frequency0.8 to 120nH 丨 110 to 1000mA1.1×0.6×0.55MWSD1005C

Same as above

MWSD1608C
Wire Wound/STDInductor for High Frequency1.6 to 560nH 丨 70 to 1150mA1.6×0.9×0.9MWSD1608C

Same as above

MWSD1005C-M01
Wire WoundInductor for High Frequency1.5 to 120nH 丨 110 to 1000mA1005 [0402 inch]MWSD1005C-M01

MWSD-C-M+Series+of+Wire+Wound+Chip+Ceramic+Inductor

MWSD1005C-M11
Wire WoundInductor for High Frequency1.3 to 5.6nH 丨 800 to 1200mA1005 [0402 inch]MWSD1005C-M11

Same as above

MWSD1608C-M01
Wire WoundInductor for High Frequency2.2 to 470nH 丨 75 to 700mA1608 [0603 inch]MWSD1608C-M01

Same as above

MWSD1005C-M8X
Wire WoundInductor for High Frequency1.3 to 75nH 丨 320 to 3150mA1005 [0402 inch]MWSD1005C-M8X

MWSD-C-M8X+series+of+Wire+Wound+Chip+Ceramic+Inductor

MWSD1608C-M8X
Wire WoundInductor for High Frequency2.2 to 390nH 丨 190 to 3200mA1608 [0603 inch]MWSD1608C-M8X

Same as above

MWSD1005-CP
Wire WoundInductor for High Frequency1.0 to 51nH 丨 360 to 2300mA1005 [0402 inch]MWSD1005-CP

MWSD-CP、CH+Series+of+Wire+Wound+Chip+Ceramic+Inductor

MWSD1005-CH
Wire WoundInductor for High Frequency56 to 220nH 丨 160 to 330mA1005 [0402 inch]MWSD1005-CH

Same as above

SDWL1608C
Wire Wound/STDInductor for High Frequency1.6 to 560nH 丨 70 to 1150mA1608 [0603 inch]SDWL1608C

SDWL-C_Series_of_Wire_Wound_Chip_Ceramic_Inductor

SDWL2012C
Wire Wound/STDInductor for High Frequency2.2 to 4700nH 丨 30 to 600mA2012 [0805 inch]SDWL2012C

Same as above

SDWL2520C
Wire Wound/STDInductor for High Frequency3.6 to 22000nH 丨 70 to 1000mA2520 [1008 inch]SDWL2520C

Same as above

SDWL3216C
Wire Wound/STDInductor for High Frequency3.3 to 1200nH 丨 300 to1000mA3216 [1206 inch]SDWL3216C

Same as above

SDWL3225C
Wire Wound/STDInductor for High Frequency3.9 to 22000nH 丨 100 to 1000mA3225 [1210 inch]SDWL3225C

Same as above

SDWL4532C
Wire Wound/STDInductor for High Frequency24 to 33000nH 丨 145 to 1000mA4532 [1812 inch]SDWL4532C

Same as above

SDWL1608C-M01
Wire WoundInductor for High Frequency2.2 to 470nH 丨 75 to 700mA1608 [0603 inch]SDWL1608C-M01

MWSD-C-M+Series+of+Wire+Wound+Chip+Ceramic+Inductor

SDWL1608C-M11
Wire WoundInductor for High Frequency2.2 to 33nH 丨550 to 1400mA1608 [0603 inch]SDWL1608C-M11

Same as above

SDWL1608C-N01
Wire WoundInductor for High Frequency1.6 to 390nH 丨 100 to 700mA1608 [0603 inch]SDWL1608C-N01

SDWL-C-N+Series+of+Wire+Wound+Chip+Ceramic+Inductor

SDWL1608-CP
Lower DCR and Hight QInductor for High Frequency1.8 to 390nH 丨 170 to 2100mA1608 [0603 inch]SDWL1608-CP

SDWL-CP+Series+of+Wire+Wound+Chip+Ceramic+Inductor

SDWL2012-CP
Lower DCR and Hight QInductor for High Frequency2.6 to 820nH 丨 180 to 2000mA2012 [0805 inch]SDWL2012-CP

Same as above
